| PSU Form Factor: | ATX 12V, PS/2 |
| M/B Form Factor: | E-ATX、ATX、Micro ATX |
| I/O Ports: | USB1.1*3+Audio / (Optional USB3.0, USB2.0+HD Audio) |
| side panel: | With metal side panel(Optional tempered glass or Acrylic side panel) |
| Hardware capability | HDD*2+SSD*2 OR HDD*1+SSD*3/ ODD*0 |
| Supports VGA Cards up to | 340mm |
| Maximum height of CPU | 160mm |
| PCI Slots | 7 |
| Fan positions | Front:12CM*3 or 14CM*3/ Rear: 12cm*1/ Top:12cm*2 or 14cm*2/Bottom: 12cm*2 |
| Support Water cooling | Front:240/280/360mm*1/Rear:120mm*1/Top:120/240mm*1 |
| Chassis dimension | L360*W210*H440mm |
| Production dimension | L423*W210*H453mm |
| Carton size: | L530*W280*H470mm |
| Material of Chassis | A grade SPCC, 0.5mm Thickness |
| Material of front panel | ABS+glass |
| 1*40'HQ QTY | 960PCS |
